Cooler Master is releasing a limited version of the MasterLiquid Flux Series flagship liquid cooler to represent 30 years of success. The performance liquid cooler features the new Mobius Series 30th Anniversary Edition fans, exclusive pump cover with the 30th Anniversary logo, as well as unique limited edition print on the radiator. The PL360 Flux 30TH Anniversary Edition has refined performance from fans to the copper base, as well as unique aesthetic design to represent our decades worth of innovation.
Slim & Sleek Radiator
Low profile radiator with superior fin density coupled with performance fans dissipates heat rapidly.
Superior Performance Ratio
Precision engineered ultra-thin spaded fins maximize microchannels accurately to target heat spots. The enlarged copper base surface optimized with ideal base thickness accelerates heat transfer.
Dual Chamber Pump
The compact Dual Chamber pump delivers the perfect balance of waterflow and pressure, decorated with the 30th Anniversary logo.
Ultimate Heat Exchange
A high speed motor utilizing a ceramic bearing impeller, which forces balanced waterflow to and from the radiator for ultimate efficiency of heat exchange.
| Product Number | MLY-D36M-A23PZ-30 |
| Exterior Color | Black |
| CPU Socket | Intel® LGA 1700 / 1200 / 2066 / 2011-v3 / 2011 / 1151 / 1150 / 1155 / 1156 socket |
| CPU Socket | AMD® AM5 / AM4 / AM3+ / AM3 / AM2+ / AM2 / FM2+ / FM2 / FM1 / TR4 socket |
| Radiator Material | Aluminum |
| Radiator Dimensions | 394 x 119.6 x 27.2 mm / 15.5 x 4.7 x 1.07 inch |
| Pump Dimensions | 89 x 75 x 40 mm / 3.5 x 2.95 x 1.57 inch |
| Pump MTTF | >210,000 Hours |
| Pump Noise Level | 15 dBA (Max) |
| Pump Connector | 4-Pin |
| Pump Rated Voltage | 12 VDC |
| Pump Power Consumption | 6W |
| Dimensions (L x W x H) | 120 x 120 x 25 mm / 4.7 x 4.7 x 1.0 inch |
| Fan Quantity | 3 PCS |
| Fan LED Type | Addressable Gen 2 RGB |
| Fan Speed | 0-2400 RPM ± 10% |
| Fan Airflow | 75.2 CFM (Max) |
| Fan Noise Level | 30 dBA (Max) |
| Fan Pressure | 3.63 mmH₂O (Max) |
| Fan Bearing Type | Loop Dynamic Bearing |
| Fan MTTF | >200,000 Hours |
| Fan Power Connector | 4-Pin (PWM) |
| Fan Rated Voltage | 12 VDC |
| Fan Rated Current | 0.18A |
| Fan Safety Current | 0.35A |
| Patent Number | US10739084B2, US11061450B2, US10409341B2, US11320874B2, US11474574B2 |
| Warranty | 5 years |
| Cooler Type | Liquid Cooler |
| Series | MasterLiquid Pro |
| Radiator Size | 360 |
