270° Tempered Glass View
Front and side glass panels with beveled edges highlight your lighting and key components.
Compact M-ATX, Full-Scale Cooling
Smaller footprint fits tight spaces—without sacrificing radiator or GPU support.
360mm Radiator Support
Delivers high-end cooling typically found in full-size ATX cases.
Vertical Cooling Layout
Up to 9 fans enable bottom-to-top airflow for effective heat management.
Pre-installed ARGB Fans with Sync
Includes 3 ARGB fans with daisy-chain support and full motherboard lighting sync.
Top & Bottom Mesh Ventilation
Large mesh zones enhance airflow and cooling performance.
RTX 50 Series Ready
GPU clearance up to 425mm for next-gen flagship graphics cards.
High-Speed I/O Panel
Features USB 3.2 Gen 2x2 Type-C (20Gbps) and dual USB 3.0 for fast, modern connectivity.
| Model Number | Black: E490-KHNN-S00, White: E490-WHNN-S00 |
| Color(s) | Black / White |
| Materials - Front Panel | Tempered Glass |
| Material - Side Panel (Left) | Tempered Glass |
| Material - Side Panel (Right) | Steel |
| Dimensions (L x W x H) | 434 x 218 x 414 mm (Incl. Protrusions), 430 x 218 x 395 mm (Excl. Protrusions) |
| Volume | 39.16 L (Liters Incl. Protrusions) |
| Motherboard Support | ITX / Micro ATX |
| Expansion Slots | 5 |
| 5.25" Drive Bays | 0 |
| 3.5" Drive Bays | 1 (Max. 2) |
| 2.5" Drive Bays | 1 |
| I/O Panel - USB Ports | 1 x USB Type C 20Gbps, 2 x USB 3.0 |
| I/O Panel - Audio In / Out | 1x 3.5mm Combo |
| Pre-installed Fans - Rear | 1x 120mm ARGB PWM |
| Pre-installed Fans - Side Mount | 2x 120mm ARGB PWM reverse fan |
| Fan Support - Top | 2x 140mm / 3x 120mm |
| Fan Support - Rear | 1x 120mm |
| Fan Support - Side Mount | 2x 120mm |
| Fan Support - Bottom | 3x 120mm |
| Radiator Support - Top | 120 / 240 / 360 (Max memory installation height: 45 mm) |
| Clearance - CPU Cooler | 170mm |
| Clearance - PSU | 250mm |
| Clearance - Graphics Card | 425mm |
| Power Supply Support | ATX |
| Warranty | 2 years |
| Size | Mini Tower |
| Series | Elite Series |
